SX-Series by ADAM Audio

Oct. 5, 2009

The new SX-Series reference monitors feature completely redesigned transducers, drivers, and electronics to provide the most transparent reproduction possible.

The new SX-Series reference monitors feature completely redesigned transducers, drivers, and electronics to provide the most transparent reproduction possible.

 All ADAM SX-Series monitors feature the new X-ART tweeter, which provides 4dB higher efficiency, increased maximum SPL of 3dB, and an expanded frequency response of up to 50 kHz.

 Other new components include an ultra-low distortion broadband A/B amplifier with 1MHz internal bandwidth and new Hexacone woofers with more linear excursion to optimize efficiency and accuracy.

 The SX-Series consists of six different models ranging from small nearfield monitors (S1X, S2X) to larger midfield monitors (S3X, S4X). The S4X and S3X models are available in vertical (S4X-V/S3X-V) and horizontal (S4X-H/S3X-H) versions.

 The S4X-H midfield monitor combines the new X-ART tweeter with a 5-inch HexaCone midrange driver and two redeveloped 9-inch HexaCone woofers. The S4X-V also incorporates the X-ART tweeter, with two 5-inch Hexacone drivers and a newly developed 12-inch Hexacone woofer optimized electronically for a bass-reflex enclosure.

 The S3X-V features the newly developed 4-inch HexaCone midrange driver and 9-inch HexaCone woofer with the X-ART tweeter to reveal the most complex nuances of any program material with an open, transparent response.

 Already a popular choice for leading studios worldwide, the S3X-H employs a 4-inch HexaCone midrange driver for detail and musical coherence in the critical midrange frequencies, along with two 7-inch Hexacone woofers that produce a deep, tight bass within the same frequency and radiation pattern.

 The compact S2X nearfield monitor uses a HexaCone 7-inch woofer, X-ART tweeter and A/B amplifier combination to produce a powerful balanced sound with surprisingly deep bass for a smaller enclosure.

 Embodying high quality sound in an ultra-compact format, the S1X monitor also combines the X-ART tweeter, A/B amplifier, and HexaCone™ woofer driven by premium PWM amplifiers for clear resolution and precise low-frequency reproduction.
